Rainbow Touch RGB Controller

Model:FL-CW-R
Size:86.5x55.6x22.8mm
Power:216W
Rainbow Touch RGB Controller with -20 to 60°C Working Temperature

Introduction

  • Technical parameters:
    • Working temperature: -20 to 60℃
    • Supply voltage: 12 and 24V DC (optional) (for orders specify voltage)
    • Output: 3 channels
    • Connecting mode: common anode
    • Transmission/receiving frequency: 433.92MHz
    • External dimensions (L x W x H): 86.5 x 55.6 x 22.8mm
    • Packing size (L x W x H): 88 x 88 x 156mm
    • Net weight: 170g
    • Gross weight: 215g
    • Output current: <6A (each channel)
    • Output power:  <216W
  • Presentation mode:
    • Gradual change model
    • Touch on button again under monochrome mode condition, RGB strip will be changed into gradual
    • change mode
    • Increasing color button will speed up the color change, decreasing color button will slowdown
  • Hopping mode: under gradual change mode condition
  • Touch on button
  • RGB strip will be changed into hopping mode
  • Increasing color button will speed up the hopping, decreasing color button will slowdown
  • Under gradual change or hopping mode, touching on switch will change one to the other
  • Close the RGB strip and restart It if you want to enter monochrome mode
  • Pay attention: the change of above two presentation mode need 4 seconds
  • Input voltage of remote control must be the same as RGB strips
  • Match the color of output wiring when connecting
  • When the color doesn't match, for example, it displays blue when touch green, or displays
  • green
  • When touching blue, please check whether the wiring is correct, in this case, exchange each other
